EMI Shielding Coating System
FlexiCoat - EMI Shielding Coating System
Package level EMI (Electromagnetic Interference) shielding spray coating with precise thickness control
Brand: SonoTek
Available
Free delivery within Singapore only
Spray-on silver-filled epoxy shielding materials for thinner, lighter device designs, enabling higher board density. Silver-filled polyester coatings are applied using ultrasonic spray following package placement.
- Complete thin film coverage of geometries with excellent uniformity
- Top surface to sidewall thickness ratio of: 1.0 to ~0.6-0.7
- High throughput (UPH)
- Excellent surface conductivity due to homogeneous distribution of particles
- Highly effective shielding of small devices
- Optimal side wall coverage in tight geometries with ultrasonic nozzle tilt and rotation
- Precise thickness control
Basic Specifications
| DIMENSIONS: 869 mm W x 1952 mm H x 1137 mm D (34” W x 76.9” H x 44.8” D) |
| WORK AREA*:
500 x 500 x 100 mm (19.69” x 19.69” x 3.94”) |
| CONTROL: Windows-based (PC included) |
| POWER REQUIREMENTS: 120V, 220V +/- 10%, 50-60 Hz |
| AIR: 551.6 kPa (80 PSI) dry unlubricated air |
| MOTORS: Servo |
| CERTIFICATION: CE |
| ULTRASONIC NOZZLE DESIGNS: AccuMist, Impact, Vortex, MicroMist, or Propel |
