Bio X6 3D Bioprinter
6-printhead 3D bioprinter that enables high-throughput 3D cell culturing and bioprinting to create the future of health.
WhatsappOverview
The BIO X6’s exceptional features maximize versatility to enhance your success in the following application areas and beyond.
1. Dual pressure regulation
2. Co-axial & Mixing printing
3. Multimaterial and crosslinking combinations in one protocol
4. The Intelligent Printhead (iPH) System gives users the utmost flexibility and interchangeability:
- UV Photocuring Toolhead
- Thermoplastic Printhead
- Electromagnetic Droplet (EMD) Printhead
- Temperature-controlled Printhead
- Standard Pneumatic Printhead
- Syringe Pump Printhead
- HD Camera Toolhead
5. Temperature controlled print bed
6. HEPA filtered clean chamber for sterile environment
7. Multiple selection of Bioinks:
- CELLINK RGD
- CELLINK FIBRIN
- CELLINK SKIN
- CELLINK BONE
- CELLINK LAMININK
Specifications
|
Outer dimensions (LxWxH), mm |
850x400x500 |
|
Weight, kg |
47.4 Kg (104.5lb) |
|
Build Volume, mm |
128×90×90 |
|
Build surface compatibility |
Multi-well plates, petridishes, glass slides |
|
Resolution XY, μm |
1 μm |
|
Layer Resolution, μm |
1 μm |
|
Pressure range (internal pump), kPa |
1-200 |
|
Pressure range (external air supply), kPa |
1-700 |
|
No. of printhead slots |
6 |
|
Photocuring sources (built-in), nm |
365, 405, 485, 520 |
|
Printbed temperature range, °C |
4-65 |
|
Printhead temperature range, °C |
4-250 (printhead specific) |
|
Filter class, chamber air-flow |
2xHEPA 14 |
|
UV-sterilization |
UV-C (287nm), 30mW output |
|
Calibration Options |
Manual and Automatic (Ultrasonic based) |
|
User Interface |
Tablet or Computer |
|
Desktop Application compatibility |
Windows |
|
Connectivity |
USB Storage, Ethernet connection, Wifi |
|
supported file formats, software |
.gcode, .stl, .amf, .3mf |
|
Power input |
100-240V, 50-60Hz, 600W |
|
Fuse |
250VAC F6 3A |
|
Structure |
Powder-coated, aluminum frame |
