Bioprinters

Experience the new standard for benchtop DLP bioprinters

Powered by CELLINK’s cutting-edge technology and harnessing 405 nm visible light, this system brings a new degree of precision and utility to the light-based bioprinter space.

Years of listening to our customers’ needs and feedback have culminated in LUMEN X™ Gen 3, packed with an array of new features and simplified workflows. Enabling greater results and allowing researchers across the world to create the future of health.

• Temperature range: Room/Ambient temperature – 60°C
• Pixel Resolution: 35 μm
• Build volume: 68x38x100 mm



Features

DESIGNED FOR LIVE CELL PRINTING

The new tight temperature control, a smooth printing mechanism, and sterility across the printing workflow, join together to increase cell viability. The autoclavable build platform has increased reusability without compromising on sterility.

GRAYSCALE PRINTING

Accurately tune the stiffness of your material and create biomechanical gradients on demand to capture the finer details of in-vivo biology

TIGHT TEMPERATURE CONTROL

Work with a wider than ever range of materials or focus on studying the thermal properties of a single material by setting the temperature anywhere between room temperature and 60 degrees Celsius.

CONSISTENT PRINTS - EVERY TIME

With a uniform distribution of intensity across the entire build platform, the LUMEN X™ Gen 3 ensures consistent crosslinking of photoinks independent of position. Levelling up the ability for array printing.

PRECISE AND COMPLEX PRINTING

An intuitive software combined with high feature resolution and optimized photoinks makes working on organ-on-a-chip models and developing microfluidic chips an effortless experience.

MODULAR BUILD PLATFORMS

With an expanded range of build platforms, print a variety of model sizes and materials with ease and say goodbye to unnecessary waste of photoinks.



Key Applications



1. MICROFLUIDICS

Complex microfluidic structures

With high precision and resolution, the LUMEN X™ Gen 3 enables the creation of complex microfluidic structures with intricate geometries for controlled fluid flow. Users can work directly with cells or seed them later. The LUMEN X™ eliminates lengthy casting processes and finally brings a much-desired, time and cost-effective solution for reproducible microfluidic fabrication.

2. MATERIAL DEVELOPMENT

Develop your own materials without workarounds

The LUMEN X™ allows users to develop and use their own materials without workarounds or extra fees, opening the door for the development of materials with unique properties and novel tissue engineering applications. With precision control over all key parameters like temperature, intensity and exposure times, researchers can glean a greater understanding of their material’s behavior.

3. TISSUE ENGINEERING

Addressing tissue-engineering challenges

Supported by the DLP technology, the LUMEN X™ enables researchers to address one of the most long-standing challenges – fabricating complex vascular networks. Coupled with grayscale printing onboard for the first time ever, the LUMEN X™ Gen 3 truly unlocks a new degree of capability in capturing in-vivo like conditions.

4. DRUG DEVELOPMENT

Providing greater insights & lowering costs

With LUMEN X™ Gen 3, we’re able to provide greater insight into the efficiency of medicinal candidates. With greyscale printing allowing multi-stiffness constructs, an increased build size, it is easier than ever to create diseased or healthy tissue constructs with fully accurate biomimetic properties. These constructs are ready to be dosed with compounds for evaluation in the early-stage compound selection process.



Photoinks and Consumables

REFORMULATED AND RETHOUGHT FOR YOUR CONVENIENCE

With our unwavering commitment to your research success, our seasoned team of biomaterial experts have developed kits with recipes and protocols, which take you from stock solutions to ready-to-print photoinks optimized for use on the LUMEN X™ Gen 3.

• PEGDA Stiff
• PEGDA Soft
• GelMA 95%
• Xcite
• Xsorb



Specifications

3D bioprinting technology	DLP printing using layer-by-layer
Pixel resolution (XY)	35 μm
LED Wavelength	405 nm (FWHM 15 nm)
Intensity range	Up to 30 mW/cm²
Build volume (XYZ)	68 x 38 x 100 mm
Temperature range	Room temperature to 60°C
Build platforms	– Glass bottom – Metal platforms – Available in three sizes
Sterility	– UVC sterilization (265 – 285 nm) – Autoclavable build platforms and sterile photoink vats
Software	Onboard: Embedded UI Desktop: DNA STUDIO ILLUMINATE Windows 11 and Windows 10 V20H2 onwards
Display	High resolution 10″ touch screen, glove friendly
Communication	USB-A, USB-C, Ethernet
Model file formats	.stl, image files (BMP, GIF, PNG, JPG)
Power supply unit	100-250 VAC, 50-60HZ, Max 26A, 320W
Instrument dimensions (WxDxH)	414 mm x 373 mm x 451 mm
Weight	15.6 kg
