SPC500D 500L Seed Preservation Chamber

Overview

• Temp. Range: -10°C to 15°C
• Temp. Sensor: Equipped with WAISALA HMP60
• Programmable Interactive Control system with 7" Touch Screen
• Equipped with smart phone APP remote control system
• Layers: 2*2 (modular shelves)
• Growing Volume: 237L*2
• Interior Dimension (W×D×H): (735x577x560mm)*2
• Exterior Dimension (W×D×H): 900x800x1940mm

Seed Preservation Chamber

Seed preservation chamber is equipped with high and low temperature protection, which the chamber will be running safe condition and even if the chamber shut down itself when the interior temperature is higher or lower than the set safety temperature, in this why to make sure the samples can be protested in case of temperature influence. Also, the chamber is equipped with temperature and humidity sensor to make to ensure the safety of instruments and samples. Low intensity light with full spectrum is optional, which is conducive to preserve the experimental sample seeds for medium-term and short-term period, and takes the advantage of improving the activity and disease resistance.

Product Details

Air Flow

Airflow for this chamber is distributed uniformly outward from both sides of the walls and back through the air pump on back side of the cabinet, which using JIUPO innovative horizontal-air-refresh distribution plenum. Airflow is sufficient to ensure uniformity as well as proper gas exchange at the leaf surface. Fresh air intake can be adjustable which also helps to ensure adequate ambient gas exchange.

Refrigeration

•  Self-contained air-cooled condensing unit with hot air bypass system for continuous compressor operation, extended life and close temperature control. An electronic modulating valve provides tight temperature control while ensuring quiet operation. Pressure transducers are included for monitoring the status of the refrigeration system.

•  Solenoid valves have extended stem for quiet and long-life operation.

•  Rear chamber wall mounted evaporator coil incorporates an air circulation fan.

Safety Limit Controls

•  Adjustable high and low temperature / pressure controls, audible alarms, and visual indicators display on the screen.

•  Controls shut down all power to the chamber, activating alarms (when the temperature / pressure returns to the normal range, the system will automatically reset).

•  Backup “high / low” alarms provide a further level of protection while visual and audible notification is provided when any alarm be activated. Contacts for connection to a remote management system are also included.

Key Product Attributes

•  Certifications: ISO9001:2015, CE, RoHS

THC300 | with Expended Temperature and Humidity Range

The JIUPO THC300 ensures absolutely constant test conditions throughout the testing area. A big advantage of this constant climate chamber is tis low space requirement and flexibility in terms of water supply. The wide temperature and humidity range make his constant climate chamber ideally suited for stress testing series.

Main Features

• Temperature range: -10°C to 15°C
• Temperature regulation with resistive temperature sensor
• JIUPO Multi Management Software JPCS19V4 Basic Edition
• Equipped with smart phone APP remote control system
• Equipped with fresh air system
• LCD to display temperature along with additional information and alarms
• Independent temperature safety device with visual and audible temperature alarm
• Easily operate with reliable regulating system which works in tandem with an HMI (Human-Machine Interface) consisting of a touchscreen display
• Intuitive touchscreen controller with time-segment and real-time programming
• Internal data logger, measured values can be read out in open format via USB
• Flush-mounted door design for better air impermeability, dual doors designed
• The chamber made of completely stainless steel (SUS304) inner parts and spraying carbon steel body shell
• Equipped with 4 stable castors and two with brakes, moveable to anywhere
