Planetary Mixer

Uniform mixing of samples in the microplate and ultrafine air bubble elimination with high speed processing.
This contributes to improved measurement result reliability.

• Multiple microplates can be set, so uniform mixing and ultrafine air bubble elimination can be performed simultaneously in a short amount of time.
• By using an exclusive adapter, mixing and degassing are possible with 18 or 96 well microplates, as well as 384 and 1536 well microplates as full range.
• Mixing and degassing of micro tubes and culture tubes are also possible by having an adapter (as an option).
• Total 12 PCR plates or microplates can be handled simultaneously.



Main applications

• Mixing of cell culture media
• Mixing of various types of biochemical assay fluids
• Mixing of beads, solvents and reagents
• Optimum for degassing and spinning down prior to inspection
• Large quantity screening, etc.
• Other PCR (replicated chain reaction) tubes and PCR tube plates
  Optimum for mixing and degassing of various types of test tubes



Specifications

Cup size	6 plates × 2 (10pcs for 384 well)
Other containers	Depending on adapters, it enables to use various container or syringe.
Speed of revolution	Settable in 9 steps
Speed of rotation	Settable in 10 steps
Settable time	Maximum 25 minutes. (5 Step total), 1 step max is 900 seconds
Step mode	5 Steps Enables to do continuous operation (condition setup) for 5 different kinds of movement
Memory channel (condition setting memory) User settable channels Fixed data channels	90CH 10CH
Power supply voltage	Three phase AC380-415VAC 50/60Hz
Power consumption	2.5kW
External dimensions	W646 × D663 × H851(mm)
Main unit weight	About 225kg
