Planetary Mixer

SK-300SII Planetary Mixer enables to operate easy with fixed rotation speed ratio against revolution speed. Carry out mixing of various materials of low to high viscosity in a short time (from ten seconds to several minutes).



Features

Mode setting according to the application

SK-300SII, the new Medium mode has been added to the existing "mixing mode/degassing mode".
Easy operation is still the same, but it offers a wider range of applications and a selection of modes suited for the material.

Equipped with a balance navigation function

The balance can be adjusted easily for the unbalance detection and balance navigation functions.

Compatible with 300 ml containers/max. 310 g

Despite its compact size, this model can be used to process 300 ml containers weighing a maximum of 310 g (gross weight)!!

Designed with a full range of safety functions

This unit is designed with such considerations for safety as top lid lock, operation lock during while the lid is open and a malfunction prevention mechanism. In addition, the unbalance error detection and a full range of functions for warning and notifying of motor problems or maintenance set alarm with peace of mind.

Unique mechanisms to the SK-300SII

Medium mode
Due to the lower ratio of rotation speed makes mixing heat sustained, so even heat sensitive materials can be used.

Wave mode
The speeds of revolution and rotation makes up and down(fast and slow) like wave motion, then enhanced more efficient mixing and dispersing.



Specifications

Cup size	300ml×1cup Mximum310g (Gross Weight)
No. of revolutions
Mixer mode	200-2000rpm
Medium Mode	200-2000rpm
Degassing mode	400-2200rpm
No. of rotations
Mixing mode	follows at 40% of revolutions
Medium Mode	follows at 20% of revolutions
Degassing mode	follows at 3% of revolutions
Time of setting	Maximum 30 minutes (Total 9 steps)
Step mode	Continues operation with 10 different action patterns(Condition setting) possible.
Memory channel	0-9channel
Power supply voltage	Single Phase AC200V-240V 50/60Hz
Power consumption	About 1,380W
External measurements	W340x D315xH370(mm)
Weight	Approx. 24kg
