Pipette

Specifications

General

Size	52(W) x 76(D) x 270(H) mm
Weight	375g
Power	Low, Medium, High
Materials	Plastic, Metal (Inside)
Gas	Ar (0.5~1.5 bar)
Gas line	4mm tube
AC Input	100-240V~50/60Hz 1.2A Max
AC Output	5V,4A



Practical Handheld Atmospheric Plasma for Researchers

Easy to Use / Simple Configuration / Affordable Price



Different Types of Tips

S-Type

Penetrating thin cracks and interior of a hollow object
e.g.) Tubes, Culture-Wares, Micro-channels *Not for Conductive Materials

A – Dense Plasma

B – Wide Plasma

C – Intense Plasma



F-Type

For all types of materials
* Less penetration than S-Type



Material

	Conductor & Semi-conductors	Thin cracks and interior of hollow objects
S-Type	X	o
F-Type	o	o



General Applications

Nano channel / Micro-fluidic device / Bio Chips

– Sterilization in nano channel
– Cleaning, Surface modifications

Micro-electronics

– Cleaning (Removal of organic contaminants)
– Surface modification

Culture Wares

– Surface modification
– Cleaning

Medical device

– Sterilization
– Surface modification

Dermatology research

– Wound healing (Tissue engineering)
– PSR (Plasma Skin Rejuvenating)

Other Uses in Bio & Medical Fields

– Tumoroids, Organoid
– 3D Patterning
– Dental applications
– Plasma Stimulated Medium (Liquid)
