Benchtop NMR Spectrometers

Compatible with 60 MHz

This NMR flow cell kit turns the instrument into an online NMR detector. It allows easy
inter-conversion of any 60 MHz benchtop spectrometer into an NMR online detector either as a stand-alone tool or in conjunction with other analytical techniques. This compact, low maintenance tool can be placed at a point of need for a smaller sample loop.

NMReady-flow allows users to:

• Understand and optimize chemical reactions in real time

• Automate repeated syntheses

• Integrate the NMReady a centralized Laboratory System

• Easy-to-install NMR Flow-through cell can be sealed from environment

• Experiments can be initiated on-board, via NMReady-CONNECT or 3rd party software



Why NMR Spectroscopy?

• NMR spectroscopy is a linear, non-destructive technique

• Inherently quantitative with little or no calibration

• Non-targeted analysis

• Chemically specific information about all molecular species present in solution at a given time, including structural connectivity



Why Benchtop NMR?

• Benchtop NMR offers significantly improved economics

• Lower capital and operating costs

• Compact, low maintenance tool can be placed at point of need for smaller sample loop

• No trained maintenance staff required

• No special safety or power requirements

• Automated acquisition & shimming routines



Data Acquisition

• Easy-to-install NMR Flow-through cell can be sealed from environment

• Small sample loop reduces lag

• Can monitor a variety of nuclei (e.g., 1H, 11B, 19F, 31P)

• Optimize reactions, identify byproducts or monitor extent of reaction

• Experiments can be initiated on-board, via NMReady-CONNECT or 3rd party software

• Data processing can be automated



Specifications

Configuration:	bottom-to-top
Material:	Mixed medium glass / PTFE
Internal diameter:	4.8 mm
Outer diameter:	5.0 mm
Flow mode:	Continuous or stopped flow
Flow rate:	<4.0 mL per minute
