Autoclave Compatible Micropipettes

Features

1.Glass-made counter window

This will not be worn out within the clean bench work and be enlarged easy to read the volume.

2. Lock mechanism

New material used for 4notch-lock improves its strength, which minimizes the lever shift from the original position.

3. Body

Materials used for pipette body have high tolerance to solvents and drop impact.

4. Plunger

Non corrosive ceramic used in the plunger. (100µL - 10000µL)

5. Seal ring

Seal ring for the Premium is tested dispensing / aspirating 600,000 times. Non-greased plunger makes it easy to maintain. (2µL-1000µL) The test was conducted by Nichiryo.The test result may vary with condition of usage.

6. Nozzle

Nozzle top has highly abrasion tolerant. (2µL-200µL)

7. Hyper Blower system

Hyper blower system improves dispensing efficiency, especially on 2µL and on 10µL dispensing.



Innovation in "Durability" and "Strength"

• Seal ring for the Premium is tested dispensing / aspirating 600,000 times.( 2μL - 200μL )
• Nozzle top is highly abrasion tolerant. ( 2μL- 1000μL )
• Non corrosive ceramic is used for the plunger ( 100μL - 10mL )

Innovation in "Stability" and "Precision"

• Hyper Blower System, longer second-push stroke, improves dispensing efficiency. (2μL,10μL,20μL)
• Easy-Calibration function provides simple lab calibration.
• Hand temperature doesn’t permeate through the body of the pipette which works to avoid affecting volume measurement. ( Patented )

Innovation in "Fatigue-Free" and "Comfort"

• New round shape of the Premium mitigates fatigue and stress from heavy workload.
• Enlarged push button makes it easy to depress.
• White body color mitigates reflection of room light.





Specifications

Cat. No	Volume Setting	Volume range(μL)	Increments(μL)	Usable tips
00-NPP-2	Digital Setting	0.1~2	0.002	BMT2-UT/UTWR, FUT/FUTRB
00-NPP-10		0.5~10	0.01	BMT2-SSW/SSWR/SSWRB, FSS/FSSRB
00-NPP-20		2~20	0.02	BMT2-SG/SGR, FSG/FSGRB
00-NPP-100		10~100	0.1	BMT2-SG/SGR, FSG/FSGRB*
00-NPP-200		20~200	0.2	BMT2-SG/SGR, FAG/FAGRB
00-NPP-1000		100~1000	1	BMT2-LG/LGR, LE/LER, FLG/FLGRB FLE/FLERB
00-NPP-5000		1000~5000	10	BMT2-X/XR
00-NPP-10000		1000~10000	10	BMT2-Z/ZR



AC & CV

Cat. No	Volume(μL)	Accuracy(%)	Precision(%)
00-NPP-2	0.2	±12.0*	≤6.0*
	1	±5.0	≤2.5
	2	±3.0	≤1.0
00-NPP-10	1	±4.0	≤3.0
	5	±1.0	≤1.0
	10	±1.0	≤0.5
00-NPP-20	2	±5.0	≤3.0
	10	±1.0	≤1.0
	20	±1.0	≤0.4
00-NPP-100	10	±2.0	≤1.0
	50	±1.0	≤0.3
	100	±0.8	≤0.3





Cat. No	Volume(μL)	Accuracy(%)	Precision(%)
00-NPP-200	20	±1.0	≤0.5
	100	±0.8	≤0.3
	200	±0.8	≤0.2
00-NPP-1000	100	±1.0	≤0.5
	500	±0.8	≤0.3
	1000	±0.7	≤0.2
00-NPP-5000	1000	±1.0	≤0.3
	2500	±0.8	≤0.3
	5000	±0.6	≤0.2
00-NPP-10000	1000	±2.0	≤0.4
	5000	±0.8	≤0.3
	10000	±0.4	≤0.2

• * The AC and CV above are measured with the disposable tips described in the catalogue.
• * The AC and CV at 0.2μL depend much on the sampling skill and the sampling condition where pipettes are used.



Stands

Cat. No	Storing capacity
00-MLT-STD2(ABS)	6pcs





Cat. No	Storing capacity
00-BM-STD(Acrylic resin)	6pcs





S-PAC

Cat. No	Content
00-SP-AP	Pipette	NPP-10(0.5~10μL)
		NPP-100(10~100μL)
		NPP-1000(100~1000μL)
	Tip	BMT2-SSR(0.5~10μL)
		BMT2-SGR(2~200μL)
		BMT2-LGR(100~1000μL)
	Tube Opener	NTO-001 (3pcs)
00-SP-BP	Pipette	NPP-20(2~20μL)
		NPP-200(20~200μL)
		NPP-1000(100~1000μL)
	Tip	BMT2-SGR(2~200μL)×2
		BMT2-LGR(100~1000μL)
	Tube Opener	NTO-001 (3pcs)
00-SP-HL	Pipette	NPP-2(0.1~2μL)
		NPP-10(0.5~10μL)
		NPP-100(10~100μL)
	Tip	BMT2-UTWR(0.1~10μL)×2
		BMT2-SSR(0.5~10μL)
		BMT2-SGR(2~200μL)
	Tube Opener	NTO-001 (3pcs)

Each package contains 3 Nichipet Premiums, 3-4 sample racked tips and 3 tube openers.
