Autoclave Compatible Micropipettes

Features

1. Glass-made counter window

This will not be worn out within the clean bench work and be enlarged easy to read the volume.

2. Pipetting / Stroke load reduction

New material used for 4 notches-lock improves its strength which minimizes the lever shifting and avoids drifting and wearing.

3. Lock mechanism

Keeps the same durability as Nichipet Premium and reduces less 70% stroke loading at maximum. Mitigates fatigue and stress from heavy workload.

4. Body

Material used has high tolerance to solvents and to drop impact. It is fully autoclavable as well.

5. Plunger

Non corrosive ceramic used in the plunger.( 100µL - 1000µL )

6. Nozzle

Nozzle top has highly abrasion tolerant. ( 2µL - 1000µL )
Non-filter designed in Nichipet Premium LT 1000μL.

7. Hyper Blower system

Hyper blower system improves dispensing efficiency, especially on 2µL and on 10µL dispensing.



Innovation in "Comfort" and "Fatigue-free"

• The durability still remain unchanged as Nichipet Premium has. Stroke loading of Nichipet Premium LT becomes less 70% at maximum than before.
• New round shape of the Premium mitigates fatigue and stress from heavy workload.
• Mltigates tension to thumb. Single hand pipetting can be done smoothly to improve operation efficiency.
• New design for reducing stroke loading and mitigating fatigue.
• Uses an enlarged counter display which is better for visibility and volume setting.

Innovation in "Durabilty" and "Strength"

Improved abrasion tolerance "Long Life"

• Seal ring for the Premium is tested dispensing / aspirating 600,000 times.( 2μL - 1000μL )
• Nozzle top is highly abrasion tolerant for 2μL through 1000μL.

Improved Durability "Tough Body"

• New material used for 4 notches-lock improves its strength which minimizes the lever shifting and avoids drifting and wearing.
• The material of the pipette body has high tolerance for solvents and drop impact.
• Ceramic plunger is used to prevent from corrosion by solvents(over 100μL type)

Innovation in "Stability" and "Precision"

• Hyper blower system improves dispensing efficiency especially on 2μL and on 10μL dispensing. (NLT- 2, 10 )
• Easy-Calibration function provides simple lab calibration.
• One-hand operation from the beginning to the end and enlarged finger rest makes the pipettes more friendly.
• Hand temperature doesn’t permeate through the body of the pipette which works to avoid affecting volume measurement. (Patented)
• Slim ejector pipe can be easy inserted into tubes to aspirate and plastic resin can avoid rust.
• Fully autoclavable. ( 121°C for 20 minutes )
• All components are manufactured and assembled in Japan to ensure the quality and reliability of the pipette.





Specifications

Cat. No	Volume Setting	Volume range(μL)	Increments(μL)	Usable tips
00-NLT-2	Digital Setting	0.1?2	0.002	BMT2-UT/UTWR, FUT/FUTRB
00-NLT-10		0.5?10	0.01	BMT2-SSW/SSWR/SSWRB, FSS/FSSRB
00-NLT-20		2?20	0.02	BMT2-SG/SGR, FSG/FSGRB
00-NLT-100		10?100	0.1	BMT2-SG/SGR, FSG/FSGRB*
00-NLT-200		20?200	0.2	BMT2-SG/SGR, FAG/FAGRB
00-NLT-1000		100?1000	1	BMT2-LG/LGR, LE/LER, FLG/FLGRB, FLE/FLERB

*The AC and CV values largely depend on the operator's and the environment under which the pipette is used.



AC & CV

Cat. No	Volume(μL)	Accuracy(%)	Precision(%)
00-NLT-2	0.2	±12.0*	≤6.0*
	1	±5.0	≤2.5
	2	±3.0	≤1.0
00-NLT-10	1	±4.0	≤3.0
	5	±1.0	≤1.0
	10	±1.0	≤0.5
00-NLT-20	2	±5.0	≤3.0
	10	±1.0	≤1.0
	20	±1.0	≤0.4





Cat. No	Volume(μL)	Accuracy(%)	Precision(%)
00-NLT-100	10	±2.0	≤1.0
	50	±1.0	≤0.3
	100	±0.8	≤0.3
00-NLT-200	20	±1.0	≤0.5
	100	±0.8	≤0.3
	200	±0.8	≤0.2
00-NLT-1000	100	±1.0	≤0.5
	500	±0.8	≤0.3
	1000	±0.7	≤0.2

• * The AC and CV above are measured with the disposable tips described in the catalogue.
• * The AC and CV at 0.2μL depend much on the sampling skill and the sampling condition where pipettes are used.



Stands

Cat. No	Storing capacity
00-MLT-STD2(ABS)	6pcs





Cat. No	Storing capacity
00-BM-STD(Acrylic resin)	6pcs





S-PAC

Cat. No	Content
00-SP-AL	Pipette	NLT-10(0.5?10μL)
		NLT-100(10?100μL)
		NLT-1000(100?1000μL)
	Tip	BMT2-SSR(0.5?10μL)
		BMT2-SGR(2?200μL)
		BMT2-LGR(100?1000μL)
	Tube Opener	NTO-001 (3pcs)
00-SP-BL	Pipette	NLT-20(2?20μL)
		NLT-200(20?200μL)
		NLT-1000(100?1000μL)
	Tip	BMT2-SGR(2?200μL)×2
		BMT2-LGR(100?1000μL)
	Tube Opener	NTO-001 (3pcs)
00-SP-HL	Pipette	NLT-2(0.1?2μL)
		NLT-10(0.5?10μL)
		NLT-100(10?100μL)
	Tip	BMT2-UTWR(0.1?10μL)×2
		BMT2-SSR(0.5?10μL)
		BMT2-SGR(2?200μL)
	Tube Opener	NTO-001 (3pcs)

Each package contains 3 Nichipet Premiums, 3-4 sample racked tips and 3 tube openers.
