Autoclave Compatible Micropipettes

Features

1. Lock mechanism

It minimizes the lever shifting and avoids drifting of volume setting during pipetting.

2. Ejector

One-hand ejection enables to minimize fatigue and provide better operation.

3. Glass-made counter window

This will not be worn out within the clean bench work.

4. Body 1

Material used has high tolerance to solvents and to drop impact.
It is fully autoclavable as well.

5. Body 2

Reduced the weight up to 30% of that of the conventional Nichiryo products.

6. Nozzle

Nozzle design for easy tip fitting.



Reduced the weight up to 30%

• Reduced fatigue for pipetting compared with the conventional products * in-house comparison

Easy maintenance

• New function provides the maintenance easily * in-house comparison

Reduced ejector load

• Improved operability by one-hand ejection remarkably * in-house comparison

Strong material for UV resistance

• This will not be worn out within the clean bench work
• Suitable for culture work in clean bench

Fully autovlavable [121°C for 20minutes ]

• Easy sterilization process

Lock mechanism for volume setting

• It minimizes the lever shifting and avoids drifting of volume setting during pipetting.

Durable body

• Material used has high tolerance to solvents and to drop impact.

4 sizes [V, S, L, K] covering wide volume range from 0.5 to 300µL
Revolving handle [360?] to fixate convenient position in pipetting

• Suitable for dispensing to 96 well micro plates





Specifications

Cat. No	Channel	Volume Setting	Volume range(μL)	Increments(μL)	Usable tips
00-NPM-8V	8	Digital Setting	0.5 ~ 10	0.01	BMT2-UT/UTWR, FUT/FUTRB
00-NPM-8S			5?100	0.1	BMT2-SG/SGR, FSG/FSGRB *
00-NPM-8L			20?200	0.2	BMT2-SG/SGR
00-NPM-8K			30?300	1	BMT2-K/KR
00-NPM-12V	12		0.5?10	0.01	BMT2-UT/UTWR, FUT/FUTRB
00-NPM-12S			5?100	0.1	BMT2-SG/SGR, FSG/FSGRB *
00-NPM-12L			20?200	0.2	BMT2-SG/SGR
00-NPM-12K			30?300	1	BMT2-K/KR

* The AC and CV values largely depend on the operator's and the environment under which the pipette is used.



AC & CV

Cat. No	Volume(μL)	Accuracy(%)	Precision(%)
00-NPM-8V 00-NPM-12V	1	±8.0	≤5.0
	5	±4.0	≤2.0
	10	±2.0	≤1.0
00-NPM-8S 00-NPM-12S	10	±3.0	≤2.0
	50	±1.0	≤0.8
	100	±0.8	≤0.3





Cat. No	Volume(μL)	Accuracy(%)	Precision(%)
00-NPM-8L 00-NPM-12L	20	±3.0	≤0.6
	100	±1.0	≤0.4
	200	±0.9	≤0.3
00-NPM-8K 00-NPM-12K	30	±3.0	≤1.0
	150	±1.0	≤0.5
	300	±0.6	≤0.3

• * The AC and CV values largely depend on the operator's skill and the environment under which the pipette is used.



Stands

Cat. No	Storing capacity
00-MLT-STD2 (ABS)	6pcs * For only Multi-Channel, 3pcs is maximum storing capacity.





Tray

Cat. No	Q'ty
00-88-TY	50
