MDS - 15 High-throughput Microwave Sample Preparation Workstation
The MDS-15 is a versatile microwave which can handle the routine work, and more complicated and demanding samples in your prep rack with a wide variety of vessels to choose from.
WhatsappOverview
The MDS-15 is a high-throughput, multi-functional closed microwave sample preparation workstation with the latest technology and a lifetime warranty on the core component. Versatility: The MDS-15 is a versatile microwave which can handle the routine work, and more complicated and demanding samples in your prep rack with a wide variety of vessels to choose from. Safety is priority number one! At Sineo we put safety at the top priority, which is why we have painstakingly designed every aspect of our microwave system with the highest level of security measures, such as the use of aerospace composite fiber vessel sleeves, and our patented Safety Bolt.
Features
- The quartz digestion vessel enables the digestion process to be visible
- Initiative wireless remote video monitoring system, together with quartz vessels, makes the reaction be seen clearly at a glance. Pictures and videos can be taken during the entire process
- 500 ml ultra-large digestion vessel meets the special requirements for the digestion of samples of up to 10 grams
- The drying rotor aides in the drying process of samples
- Sineo’s patented safety bolt design eliminates the need for explosion-proof membranes and other costly consumables
- The Aerospace composite fiber outer vessel ensures the highest level of vessel security
- Large 65L stainless steal chamber and dual magnetron structure, is designed for high energy and uniform microwave field
- With over 20 years of experience in the industry Sineo is known asa innovation leader with numerous patents
Specifications
|
Name of reaction vessel |
16 GP-100 ultrahigh strength frame closed vessel |
8 QZ-100 high temperature/pressure visual closed quartz vessel |
8 LV-500 ultra large capacity digestion vessel carousel |
|
Model of reaction vessel |
GP-100 |
QZ-100 |
LV-500 |
|
Processing capacity in one batch |
16 |
8 |
8 |
|
Inner vessel material |
TFM |
Pure Quartz |
TFM |
|
Explosion-proof outer vessel material |
Aerospace composite fiber Xtra Fiber |
N/A |
Aerospace composite fiber Xtra Fiber |
|
Frame structure of digestion rotor |
Independent frame structure of each digestion vessel |
Independent frame structure of each digestion vessel |
Integrated high strength alloy rotary carousel |
|
Reaction vessel volume |
100ml |
100ml |
500ml |
|
Maximum design pressure |
10MPa(1500psi) |
10MPa(1500psi) |
4MPa (600psi) |
|
Maximum temperature |
300°C |
310°C |
230°C |
|
Maximum sample amount |
0.5-1.0g |
0.5-1.0g |
5-10g |
|
Resistance to HF |
Yes |
No |
Yes |
|
Magnetic stirring function |
No |
No |
Yes |
|
Typical application |
Food, soil, metal, alloy, cosmetic, plant, etc. |
Fat, oil, plastic, coal, etc. |
Biological samples, environmental samples, etc. |
|
Power |
220-240 VAC 50/60Hz 16A |
|
Microwave source |
2450MHz, dual magnetron design |
|
Installed power |
3600W |
|
Maximum output power |
2200W, non-pulse continuous automatic variable frequency control |
|
Cavity |
65L stainless steal industrial grade professional chamber, multi-layer chemical resistant PFA coating |
|
Door design |
6 layer steel structure and popup cushioning explosion-proof sliding chamber door (Auto-Pop) design, electronic and mechanical dual-control door lock |
|
Video monitoring system (Optional) |
Wireless video monitoring system, mobile phones and tablets can realize the observation and monitoring of the reaction |
|
Turntable design |
Load 16 GP-100 closed digestion vessels at same time |
|
Pressure measurement and control system |
Piezoelectric crystal pressure sensor, pressure control range :0-10MPa (1500 psi), accuracy ± 0.01MPa |
|
Temperature measurement and control system |
High-precision platinum resistor temperature sensor, temperature range :0-300°C, accuracy ±1°C; IR temperature sensor as optional, temperature range :0-300°C, accuracy ±1°C. |
|
Outer vessel material |
Explosion-proof outer vessel made of aerospace composite fiber. high temperature and pressure resistance reach 600?and 66 Mpa(10000psi). |
|
Inner vessel material |
Modified TFM material |
|
Chamber exhaust system |
High-power anticorrosion axial fan, 20 minutes cooling time (from 200°C to 60°C) |
|
Working environment |
0-40 °C, 15-80%RH |
|
Whole physical size/weight |
550*670*700 mm, 70 KG |
