Liquid Nitrogen Container

CryoMajor Series liquid nitrogen containers are economical small and medium size liquid nitrogen containers for long term static state storage. CryoMajor Series include two types, large capacity and long shelf life. CryoMajor Series are made of high strength and light-weight aluminum alloy. There is multilayer superior performance thermal insulation inside.
Various accessories are optional.
Mainly apply to animal husbandry and laboratories.



Features

CryoMajor Series, with Canisters

•     High strength and lightweight alu-minum construction
•     Ultra-low evaporation losses
•     Numbered index location points for canisters
•     Mobile roller bases optional
•     Lockable lids
•     Straw storage
•     LN2 pump optional
•     5-year vacuum warranty



Specifications

Model	Liquid N2   Capacity(L)	Neck Diameter   (mm)	Number of Canister	Overal Height(mm)	External Height   (mm)	Static Evaporation(L/D)	Number of Straw (0.5ml)	Number of Straw   (0.25ml)
CryoMajor   2/35	2	35	3	410	180	0.08	165	330
CryoMajor   3/50	3	50	6	425	224	0.12	792	1788
CryoMajor   6/50	6	50	6	460	285	0.12	792	1788
CryoMajor   10/50	10	50	6	530	305	0.11	792	1788
CryoMajor   15/50	15	50	6	605	305	0.12	792	1788
Model	Liquid N2 Capacity (L)	Neck Diameter (mm)	No. of  Canister	Overal Height (mm)	External Diameter (mm)	Static Evaporation (L/D)	No.   of  Straws		No.of   Straws
							(1-level Canister)		(2-level Canister)
							0.5ml	0.25ml	0.5ml	0.25ml
CryoMajor 13/50L	13	50	6	623	310	0.12	——	——	1284	2832
CryoMajor 20/50(L)	20	50	6	672	394	0.12	792	1788	1284	2832
CryoMajor 20B/50	20	50	6	672	394	0.2	792	1788	1284	2832
CryoMajor 25/50(L)	25	50	6	700	394	0.14	792	1788	1284	2832
CryoMajor 30/50(L)	31.5	50	6	705	462	0.12	792	1788	1284	2832
CryoMajor 30B/50	31.5	50	6	705	462	0.2	792	1788	1284	2832
CryoMajor 30/80L	31.5	80	6	710	462	0.21	——	——	3624	8460
CryoMajor 30/125	31.5	125	6	705	462	0.35	——	——	9048	19944
CryoMajor 35/50(L)	35.5	50	6	750	462	0.12	792	1788	1284	2832
CryoMajor 35B/80	35.5	80	6	753	462	0.3	2244	5022	3624	8460
CryoMajor 35/80(L)	35.5	50	6	750	462	0.12	——	——	3624	8460
CryoMajor 35/125(L)	35.5	125	6	748	462	0.41	5124	11640	9048	20760
CryoMajor 47/127L	47	127	6	718	508	0.36	——	——	9048	19944
CryoMajor 47/127T(L)	47	127	10	718	508	0.36	8540	19920	15080	33240
CryoMajor 50B/50(L)	50	50	6	811	462	0.23	792	1788	1284	2832
CryoMajor 50B/125(L)	50	125	6	818	462	0.45	——	——	9048	19944
